![](../images/dvr/X3/feature.jpg) |
- 4 กล้อง Real-Time (100/100 FPS @960H)
- 8 กล้อง Real-Time (200/200 FPS @D1/960H)
- 16 กล้อง Real-Time (400/400 FPS @D1/960H)
- 32 กล้อง Real-Time (800/800 FPS @D1/960H)
- บันทึกภาพละเอียดสูงWide-D1(960H) /FULL-D1(760H) Real-time h.264 ขนาด4/8กล้อง , 2เสียงG.711A
- บันทึกภาพ / เสียงและส่งภาพผ่านเน็ตเวิร์คที่ความละเอียด 960H/Full-D1/Q960H/CIF/QQ960H
- FAT32 HDD, S.M.A.R.T ,RAID,และแบ่งโควตาพื้นที่จัดเก็บ
- ฟรี DDNS ServerและuPnP ทำออนไลน์ได้ในตัว
- Quick Play ค้นหาด่วน
- ระบบค้นหาและล็อคไฟล์วีดีโอสำคัญไว้เพื่อป้องกันการบันทึกทับ
- รองรับ Gigabit Port ความเร็วสูงในเครื่อง
- ตรวจจับอุณหภูมิ,การปิดบังหน้าเลนส์:ส่งเสียงร้อง ส่งอีเมล์ Relay Output ฯลฯ
- ช่องต่อSensor input และAlarm output, RS485
- โปรแกรม CMS เชื่อมโยง X3 และ Series7 DVR เข้าด้วยกัน
- สายพ่วงเซ็นเซอร์รีโมทคอนโทรล(PS-X3208WD,X3216WD)
- เมนู GUI ภาษาไทย-อังกฤษ ใช้งานง่าย สวยงาม
|
|
Model |
PS-X3104WD |
|
Description |
4CH@960H Real-time |
Resolution & Compression |
4*960H |
Software performance |
960H Q960H FD1 CIF |
Audio input |
G.711A, 2-ch, RCA connector (2.0 Vp-p, 1 kΩ) |
Intercom
Input/Output 3mm |
Share with audio input |
VGA(DB15) |
1-ch, |
HDMI |
1-ch,1080P with Alarm Audio |
|
USB |
2 in the back |
SATA HDD |
1 |
Network RJ45 |
100Mbps |
Alarm input |
4 |
Alarm output |
1 |
RS485 |
Half-duplex |
Power supply |
DC 12V 24W |
Size(MM) |
254*168.4*49.5 |
|
iOS/Andriod |
Live/Playback/Configuration |
CE Certification |
Yes |
|
FCC Certification |
Yes |
RoHS Certification |
Yes |
Model |
PS-X3108D |
|
Description |
8CH@D1 Real-time |
Resolution & Compression |
8*D1 |
Software performance |
8CH * FD1 |
Audio input |
G.711A, 2-ch, RCA connector (2.0 Vp-p, 1 kΩ) |
Intercom
Input/Output 3mm |
Share with audio input |
VGA(DB15) |
1-ch, |
HDMI |
1-ch,1080P with Alarm Audio |
|
USB |
2 in the back |
SATA HDD |
1 |
Network RJ45 |
100Mbps |
Alarm input |
4 |
Alarm output |
1 |
RS485 |
Half-duplex |
Power supply |
DC 12V 24W |
Size(MM) |
254*168.4*49.5 |
|
iOS/Andriod |
Live/Playback/Configuration |
CE Certification |
Yes |
|
FCC Certification |
Yes |
RoHS Certification |
Yes |
|
Model |
PS-X3116D |
|
Description |
16CH@D1 Real-time |
Resolution & Compression |
16*D1 |
Software performance |
16CH * FD1 |
Audio input |
G.711A, 2-ch, RCA connector (2.0 Vp-p, 1 kΩ) |
Intercom
Input/Output 3mm |
Share with audio input |
VGA(DB15) |
1-ch, |
HDMI |
1-ch,1080P with Alarm Audio |
|
USB |
2 in the back |
SATA HDD |
1 |
Network RJ45 |
100Mbps |
Alarm input |
4 |
Alarm output |
1 |
RS485 |
Half-duplex |
Power supply |
DC 12V 24W |
Size(MM) |
440*289.5*68.3 |
|
iOS/Andriod |
Live/Playback/Configuration |
CE Certification |
Yes |
|
FCC Certification |
Yes |
RoHS Certification |
Yes |
Model |
Feature |
PS-X3208WD |
PS-X3216WD |
PS-X3232WD |
Housing |
Housing |
1.5U |
Operation System |
Operation System |
Embedded LINUX |
Video |
Compression |
H.264 |
Input |
8ch BNC(1 Vp-p,75Ω) |
16ch BNC (1 Vp-p,75Ω) |
32ch BNC (1 Vp-p,75Ω) |
Output |
1 BNC, 1 VGA,1 HDMI,1 SPOT |
Dual Stream |
Support |
Audio |
Compression |
G.711A |
Input |
2ch RCA(1KΩ,Vp-p=2.0V LINE) |
4ch BNC(1KΩ,Vp-p=2.0V LINE) |
Output |
1ch RCA(600Ω,Vp-p=2.0V LINE) |
Bidirectional Talk |
3.5mm MIC Input Interface |
|
Alarm |
Input |
4 |
Output |
1 |
Preview |
Resolution |
FD1: PAL(704×576), NTSC(704×480)
960H: PAL(928×576), NTSC(928×480) VGA/HDMI:1920*1080 |
Display |
1ch/ 4ch/ 8ch/ 9ch |
1ch/ 4ch/ 8ch/ 9ch/ 12ch/ 16ch |
1ch/ 4ch/ 8ch/ 9ch/ 12ch/ 16ch |
Sequence |
Yes |
Privacy Masking |
4 zones Maximum, On DVR |
Recording |
Resolution |
8ch 960H/FD1/Q960H/CIF |
16ch 960H/FD1/Q960H/CIF |
32ch 960H/FD1/Q960H/CIF |
Recording Mode |
Manual, Schedule, Motion, Alarm |
Recording Quality |
CBR, VBR |
Recording Interval |
Pre-record: 5~30 sec., Post-record: 0~180sec. |
Playback |
Channel |
4ch/8ch/16ch 960H Full Channels Realtime Playback |
Search Mode |
Time, Date, Record Mode, Smart Search,Quick Playback |
Privacy Masking |
4 zones Maximum, On DVR and PC |
Network |
Connection Way |
Support 3G aircard, WLAN |
Remote Operation |
WEB( IE, Chrome, Firefox, Safari) |
Email |
|
With image |
Mobile |
|
Support (IPhone, Android, iPad) |
Backup |
|
USB devices & Network download |
HDD |
|
2 HDD(Max support 4TB each) |
4 HDD(Max support 4TB each) |
External Interface |
Network Interface |
1 RJ-45 10/100M/1000M adaptive Ethernet Interface |
USB Interface |
2 Interfaces( Mouse control & Backup) |
General |
Auxiliary Interface |
1 RS-485(FDX),1 IR Extension Cord |
Power Supply |
220±30% V,50±3% Hz / 110±20% V,60±3% Hz |
Power Consumption(Full Load) |
27W |
33W |
60W |
Working Environment |
-10℃~+45℃ / 15%~85%RH |
Dimension |
440mm×290mm×66mm(W×D×H) |
Weight |
2.7 KG(without HDD) |
2.8 KG(without HDD) |
4.0 KG(without HDD) |
* Product Design and Specifications are subject to change without prior notice.
